High Torque Stepper Motors from 0.01 to 50Nm. NEMA08,NEMA17,NEMA23,NEMA34,NEMA43,NEMA53



A series of step motors that have been designed by JVL for use with the entire range of JVL Step Motor Drivers and Controllers. They are high torque step motors especially made for mini- and microstep operation.

  • Highest torque density rating in the industry
  • High torque-to-inertia for faster start and stop
  • Rugged design and long life bearings
  • High power, cooler running, rare-earth magnet design

  • Exposed-lamination housing, optimized for high torque and smooth, accurate microstepping
  • Standard NEMA08-53 mounting
  • Facilities for encoders, double shaft, different shaft types, etc.
  • Ground terminal for correct EMC shielding
  • High axial and radial shaft load
  • Cost-effective alternative to servo motors
  • Low noise
  • Option for planetary gearhead
  • Protection up to IP67
Size
Nm
Stepper Motors MST081A03 and MST82A03
20mm
(0.8 inches)
NEMA08
0.01Nm - 0.03Nm

Two mini stepper motors for applications where small size is a must.
Stepper Motors MST11x
28mm
(1.1 inches)
NEMA11
1.2Nm - 4.0Nm

Mini stepper motor for applications where small size is a must.
Stepper Motors MST17xxx3
43mm
(1.7 inches)
NEMA17
0.12Nm - 0.8Nm
(17.0 oz-in) -
(113.3 oz-in)

A series of high torque stepper motors.
Stepper Motors MST17xxx2
43mm
(1.7 inches)
NEMA17
0.07Nm - 0.46Nm
(9.9 oz-in) -
(65.14 oz-in)

A series of high torque stepper motors
with high precision.
Stepper Motors MST23xxx3
57mm
(2.3 inches)
NEMA23
0.48Nm - 2.6Nm
(68.0 oz-in) -
(368.2 oz-in)

A series of high torque stepper motors.
Stepper Motors MST23xxx2
57mm
(2.3 inches)
NEMA23
0.32Nm - 2.1Nm
(45.3 oz-in) -
(297.4 oz-in)

A series of high torque stepper motors
with high precision.
Stepper Motors MST23xxx2
20 - 57mm
(0.8 - 2.3)
NEMA08 - 23
0.01Nm - 2.6Nm
(14.2 oz-in) -
(368.2 oz-in)

A series of high torque stepper motors
with encoders mounted.
IP65 and IP67 stepper motor MSW23x.
57mm
(2.3 inches)
NEMA23
1.1Nm - 2.0Nm
(155.8 oz-in) -
(283.2 oz-in)

A series of high torque stepper motor for wash down or harsh industrial operation
IP65 and IP67 stepper motor MSW24x
60mm
(2.4 inches)
NEMA24
1.3Nm - 3.0Nm
(184.1 oz-in) -
(424.8 oz-in)

A series of high torque stepper motor for wash down or harsh industrial operation
IP65 and IP67 stepper motor MSW34x.
87mm
(3.4 inches)
NEMA34

5.0Nm - 9.2Nm
(708.1 oz-in) -
(1302.8 oz-in)

A series of high torque stepper motor for wash down or harsh industrial operation
Stepper Motors MST34xxx3
87mm
(3.4 inches)
NEMA34
3.2Nm - 12.5Nm

A series of high torque stepper motors.
Stepper Motors MST34xxx2
87mm
(3.4 inches)
NEMA34
3Nm - 9Nm

A series of high torque stepper motors
with high precision.
Stepper Motors MST43xxx2
109mm
(4.3 inches)
NEMA43
10Nm - 24Nm

A series of high torque stepper motors.
Stepper Motors MST51x
134mm
(5.1 inches)
NEMA51
27Nm - 50Nm

A series of high torque stepper motors.
Note, the measurements in inches fits the nema standard, the measurements in milimeters is the actual flange size.
