Detailed MAC MotorSelection Chart

Basic MAC motors (Select expansion module to get a complete system, click here)
Model
Power
W/Nm
Velocity
Unbal.
Async.
Serial
Interface
Bal.
Async.
Serial
Interface
±10V
Analog
Input
Pulse
Inputs
Pulse
Outputs
Digital
User
Inputs
Digital
User
Outputs
Protec-
tion
Class
12-48VDC
46-134W
0.11-0.48Nm
0-4000RPM
0-2700RPM
for MAC141
5VTTL
19.2kbaud
Full
Duplex
RS422
19.2kbaud
Full
Duplex
Yes RS422
2.5MHz
or
150kHz
(LP)
RS422
4096
cpr
No Motor
status
2xNPN
25mA
IP42
MAC140-A3
MAC141-A3
12-48VDC
134W
0.32-0.48Nm
0-4000RPM
0-2700RPM
for MAC141
5VTTL
19.2kbaud
Full
Duplex
RS422
19.2kbaud
Full
Duplex
Yes RS422
2.5MHz
or
150kHz
(LP)
RS422
4096
cpr
No Motor
status
2xNPN
25mA
IP67
1)
MAC100
(stainless)

MAC101
(stainless)

12-48VDC
100W
0-4000RPM
0-2700RPM
for MAC101

5VTTL
19.2kbaud
Full
Duplex

RS422
19.2kbaud
Full
Duplex
Yes RS422
2.5MHz
or
150kHz
(LP)
RS422
4096
cpr
No Motor
status
2xNPN
25mA
IP67
1)

MAC400-D2
MAC400-D5
(with brake)
115-230VAC
400W
1.3Nm
0-300RPM
5VTTL
19.2kbaud
Full
Duplex
2xRS422
19.2kbaud
Full
Duplex
Yes
RS422
2.5MHz
or
150kHz
(LP)
RS422
8192
cpr
4IO
3.3V logic
2)
Motor
status
2xNPN
25mA
IP55
3)

MAC402-D2
MAC402-D5
(with brake)
12-48VDC
400W
1.3Nm
0-300RPM
5VTTL
19.2kbaud
Full
Duplex
2xRS422
19.2kbaud
Full
Duplex
Yes RS422
2.5MHz
or
150kHz
(LP)
RS422
8192
cpr
4IO
3.3V logic
2)
Motor
status
2xNPN
25mA
IP55
3)

MAC800-D2
MAC800-D5
(with brake)
115-230VAC
750W
2.4 Nm
0-3000RPM
5VTTL
19.2kbaud
Full
Duplex
RS422
19.2kbaud
Full
Duplex
Yes
RS422
2.5MHz
or
150kHz
(LP)
RS422
8000
cpr
4I
+
RS422
2)
Motor
status
2xNPN
25mA
IP42

MAC1500-D5
(with brake)
3x480VAC
1500W
5.0-15.0Nm
0-3000RPM

5VTTL
19.2kbaud
Full
Duplex
2xRS422
19.2kbaud
Full
Duplex
Yes
RS422
2.5MHz
or
150kHz
(LP)
RS422
8192
cpr
4IO
3.3V logic
2)
Motor
status
2xNPN
25mA
IP55
3)

MAC3000-D2
MAC3000-D5
(with brake)
3x480VAC
3000W
9.55-28.7Nm
0-3000RPM

5VTTL
19.2kbaud
Full
Duplex
2xRS422
19.2kbaud
Full
Duplex
Yes
RS422
2.5MHz
or
150kHz
(LP)
RS422
8192
cpr
4IO
3.3V logic
2)
Motor
status
2xNPN
25mA
IP55
3)

1) IP67 protection class is only possible if basic MAC motor and expansion module both are the same IP class.
2) Under development
3)Optional IP66
