Ethernet/IP Module for MAC - MAC00-EIx


Ethernet/IP with M12 connectors few IO. MAC00-EI4:
  • 8 pin connector for IO. Total 4x M12
  • Control and setup through Ethernet/IP
  • Ethernet/IP input and output. Switch built-in.
  • For built-in PLC with ( MAC400-3000 ) or HWI for MAC050-141 etc.
  • 1 digital input for enable, limit etc.
  • 1 analogue input for zero search and adjustment etc.
  • 1 digital opto-isolated output up to 15mA for In Position, Error etc.
  • Protection IP67
  • RS232 interface

Ethernet/IP with M12 connectors many IO. MAC00-EI41:
  • 17 pin M12 connector for IO. Total 4x M12
  • Control and setup through Ethernet/IP
  • Ethernet/IP input and output. Switch built-in
  • For built-in PLC with ( MAC400-3000 ) or HWI for MAC050-141 etc.
  • 4 digital inputs for enable, limit etc.
  • 2 digital opto-isolated outputs up to 15mA for In Position, Error etc.
  • 2 analogue inputs for zero search or adjustment etc.
  • RS422 for encoder or pulse/direction IO
  • Protection IP67
  • RS232 interface


Ethernet/IP Module for MAC MAC00-EIx
RS 232
Ethernet/IP Module for MAC - MAC00-EIx
Ethernet/IP Module for MAC MAC00-EIx
Ethernet/IP Module for MAC MAC00-EIx


The Industrial Ethernet Protocol (Ethernet/IP) was originally developed by Rockwell Automation and is now managed by the Open DeviceNet Vendors Association (ODVA).
It is an already well established Industrial Ethernet communication system with good Real-Time capabilities.

Ehernet/IP has a strong presence in America and Asia and has been selected by General Motors as a plant wide communication system for all GM factories worldwide.

Ethernet/IP is standardized in the International standard IEC 61158 and Ethernet/IP devices are certified by ODVA for interoperability and conformance.

EtherNet/IP extends commercial off-the-shelf Ethernet to the Common Industrial Protocol (CIP) – the same upper-layer protocol and object model found in DeviceNet and ControlNet.

CIP allows Ethernet/IP and DeviceNet system integrators and users to apply the same objects and profiles for plug-and-play interoperability among devices from multiple vendors and in multiple sub-nets. Combined, DeviceNet, ControlNet and Ethernet/IP promote transparency from sensors to the enterprise software.
