Accessories for Quickstep Integrated Stepper Motors and SMC85 Stepper Motor Controller


JVL is concerned that our customers can obtain the necessary accessories from us in order to easily beeing able to build a complete motion control system.
We therefore offer a wide range of accessories as listed below. If you do not find what you are looking for please contact us and we will do our utmost to help you.



QuickStep motor Accessories Item Protection Class
PSU24-075
PSU24-075
PSU 24VDC/3.2A, 75W.
85-264VAC DIN
Switch-mode power supply.
UL/CE approved.
DIN rail.
HxDxW = 126x100x56mm.
-
PSU48-240
PSU48-240.
PSU48VDC/5A. 240W.
100-240 VACSwitch-
mode power supply.
UL/CE approved.
DIN rail.
HxDxW = 126x100x126mm.
-
PSU80-4
PSU80-4.
PSU80VDC. 400W.
115/240 VAC
power supply.
19" rack
HxDxW = 128.5x171x108mm.
-
USB-RS232/485-OPTO
USB to RS232/422/485 adaptor
-
RS485-USB-ATC-820
USB to RS485 adaptor
-
RS485-M12-1-5-5
Programming cable RS485 for M12, 5pin 5m
Only for MIS23x, MIS34x/MIS43x with Q5 option
-
RS485-
M12-1-17S
Programming cable RS485 for M12, 17pin 5m
Only for MIS34x/MIS43x with P6 or Ethernet Ex option
-
WI1000-M12xyAzzN
M12 connector and free end
x: F for female. M for male.
y: No. of pins. 5=5pin. 8=8pin.

zz: 05 for 5 metre. 20 for 20 metre
IP67
1)
WI1025-M12F5AF5AM5A
M12 Y-connector for CAN bus.
2xfemale 5-pin and 1x male 5pin
IP67
1)
WI0034

PA0160 cable DSUB26 - MAC00-R4

-

WI0036

PA0160 cable DSUB26 - MIS, 2 x 8pin M12, for QuickStep - 1,0 m

-

WI0064

PA0160-24 cable DSUB26 - MIS34 - M17, for QuickStep - 1,0 m

-

WP2101, WP2105, WP2120

Motor cable for SMC85 in housing 1, 5 and 20m M16, 6 pin with 6 wire

-

SMC85-CONKIT1-PWR

Motor connector kit M16 for SMC85

-

PA0160-24
Test Box for testing and program
development with MAC and QuickStep Motors
-
PA0190

PA0190 is a IO gateway for MACmotor and MISmotor with 17 pin M12 connectors. It can be MACmotor Industrial Ethernet modules MAC00-Ex41 or MIS34x / MIL34x motor with 17 pin M12 connector. The gateway split the 17 pin connector into 4 pcs M12 connectors with different functions.

IP67
MacTalk
Setup, diagnostic and programming
tool for integrated stepper motors QuickStep and integrated servo motors MAC motor.
-
MacRegio
Try for yourselves and figure out how simple the MacTalk protocol is. This tool will help you implement the protocol into your own system. See the byte sequence that is to be sent and received on the serial line.
-
MACCOMM
Active X/ OCX software driver for windows programs
for fast and easy implementation of
a QuickStep or MAC motor on
a PC with RS232, RS485 or USB interface.
-
DEMO_MIS340_MAC400
Demo suitcase without content made for MIS340 and MAC400-D2 or similar sized motor.
-
1) IP55 or IP67 protection class is only possible if basic QuickStep motor is the same IP class.
